Pass This Message Along

When an operator in mission control sends a command to a rover on Mars, the signal first reaches one of the satellites orbiting the Red Planet. The trouble is that the rover happens to be on the night side, and the satellite that received the command can’t see it at all. Its neighboring satellites, on the other hand, can see it perfectly.

So it does the only sensible thing: it tells everyone it can hear. They repeat it to their neighbors, those to the next ones - until the command reaches a satellite that happens to have the rover in range, and that one drops it down to the surface. No one along the way knows where the rover is. No one knows the map of the network. Everyone knows just one rule: pass it on.

That’s flooding - and in this naive form it just sank the entire constellation.

Caught in a loop

Let’s look at our constellation. Satellite A receives a command and sends it to its neighbors B and D. B forwards it to C, C to D, and D - not knowing it has already been going around - sends it back to A. A treats it as new and broadcasts it again. Copies multiply and circle the orbits forever.

We call this a broadcast storm: a single message turns into an avalanche of copies that never goes quiet. So every satellite has to ask itself two questions before it forwards anything.

I’ve seen this already - skip it

First question: have I already seen this message?

To answer it, every message needs an identifier assigned once, when it’s created - never on a subsequent relay.

@dataclass(frozen=True)
class Message:
    id: str          # assigned once, at the origin - never changes on relay
    ttl: int         # hops remaining - we'll come back to this
    payload: bytes

If this sounds like the idempotency key from You Can’t Undo a Command Sent to Mars, that’s because it is. There the rover rejected duplicate commands; here every satellite rejects duplicates of a message it has already passed on.

@dataclass
class Satellite:
    #: IDs we've already forwarded, so we never forward them twice.
    seen: set[str] = field(default_factory=set)

    def relay(self, msg: Message) -> None:
        if msg.id in self.seen:      # already handled -> drop it, kill the loop
            return
        self.seen.add(msg.id)

        if self.sees_rover():
            self.deliver(msg)        # dropped down to the surface
            return
        ...

A single simple set is enough to stop messages from circling forever: a message passes through each satellite exactly once.

Hop counter - TTL

Second question: how long should I keep forwarding this message?

A satellite can reset, memory is limited, and after a restart the seen set is wiped. Then an old, already-forgotten message can set off on another lap around the constellation.

This is where the hop counter (TTL) comes in - the maximum number of hops between satellites, decreasing after each jump.

        if msg.ttl <= 0:             # travelled far enough -> give up
            return

        hop = replace(msg, ttl=msg.ttl - 1)
        for neighbor in self.in_range():
            neighbor.relay(hop)      # pass it on

TTL is a safeguard independent of memory: even if every other mechanism fails, a message’s lifespan is capped in advance. We pick the counter to match the size of the constellation, with a small margin.

Flooding doesn’t know the route - and that’s the point

Why flood the whole network when a single good route to the rover would do? Because a route requires knowledge - who is where, who connects to whom, and whether they can relay a message right now. And in a moving satellite constellation that knowledge goes stale by the minute.

Flooding doesn’t need that knowledge. We pay with redundant traffic, but in return we get resilience: if any path to the rover exists, the message will find it. Copies travel along different routes, so cutting one of them doesn’t stop the command from arriving.

Your cluster does the same thing

You don’t need a satellite to run this - you most likely already have it in production.

Gossip. Redis Cluster, Consul, Cassandra, or Serf discover who’s alive in the cluster exactly this way: a node “gossips” about its state to random neighbors, those pass it on, and after a few rounds the whole cluster knows the same thing. No central registry, resilient to any single node going down. The same epidemic “pass it on”.

WebSocket fan-out. You have several nodes holding connections. A message lands on node A, but the recipient is hanging off node C. A doesn’t know every connection, so it broadcasts over a backplane (Redis pub/sub, the Socket.IO adapter, the SignalR backplane), and the right node delivers. A satellite that can’t see the rover is the node that isn’t holding the target connection.

In the constellation	In your system
”pass it on” to neighbors	gossip membership (Redis Cluster, Consul)
dedup by message id	dedup by message-id on the backplane pub/sub
TTL / hop counter	max hop / drop on a repeated event
broadcast storm	re-broadcast loop, event storm

And that broadcast storm from the first section? It’s the same failure that lets a misconfigured pub/sub loop an event between two services and take both of them down. The same seen set that calmed the ring saves your backplane too.
